Brand Name : | ZKHY |
Model Number : | ZK-RFID406 |
Certification : | ZKHY |
Price : | 535 usd /pcs |
Payment Terms : | T/T, Western Union,paypal |
Supply Ability : | 10000pcs/month |
Delivery Time : | 5-8 work days |
Compact Schools Usb Uhf Rfid Reader For Rfid Based Attendance System
General Descripation
ZKHY UHF High Performance Fixed Reader is designed upon fully self-intellectual property.
Based on proprietary efficient digital signal processing algorithm,it supports fast tag read/white operation with high identification rate.
It can be widely applied in many RFID application systems such as logistics,access control, and anti-counterfeit and industrial production process control system
Features:
• Self-intellectual property;
• Based on R2000 design,excellent multi-tag anti-colision operation,fully support EPC CLASS1 G2 iso18000-6B protocol tags
• 860-960 MHzfrequency band (frequency customization optional);
• FHSS or Fix Frequency transmission,support RSSI(optional);
• RF output power up to 30dbm(adjustable);
• 4 TNC antenna ports support antenna auto-tuning and antenna testing;
• Support anto-running,interactive an trigger-activating work mode;
• Low power dissipation with single +9DC power supply ,POE is optional;
• Support RS232,RS485,USB (Host/Slave),TCP/IP interface,WIFI and some other communication port for choice;
• Provide DLL and Demonstration Software Source code to facilitate further development;
• High reliability design , meet the requirements of harsh working enviroment.
4-Channel Impinj R2000 chip UHF RFID Fixed Reader Ultra high frequency rfid active/answer reader,RS232 RS485 WLAN wiegand output
![]() |
