Product name: Portable UHF RFID Bluetooth Reader
Model number:ZK-RFID9816UBT
Size:110mm×50mm×5.8mm
GENERAL DESCRIPTION
ZK-RFID9816UBT is a high performance and portable ISO18000-6C (EPC
C1G2) Protocol UHF tag reader. It is designed upon fully
self-intellectual property and supports fast tag read/write
operation with high identification rate. It can be widely applied
in many RFID application systems such as stock management,
traceability system, personnel identification, access control and
anti-counterfeit system.
FEATURES
l Fashion, thin and well portable design;
l Ultra low power design, over 3 hours continuous reading tag and over 1 day in standby;
l Support interactive and trigger-activating work mode;
l Support ISO18000-6C (EPC C1G2) protocol tag;
l 902~928MHz or 865~868MHz frequency band(frequency customization
optional);
l FHSS or Fix Frequency transmission;
l Built-in TX/RX antenna with up to 1000mm effective distance*;
l RF output power from 0 to 26dbm (adjustable) with RSSI supported;
l Multiple tag anti-collision>50pcs/s, multiple tag inventory speed>50pcs/s;
l Tag buffer size: 370PCS Max.128bitsEPC or 120PCS Max.496bitsEPC;
l Support Bluetooth 4.0. Built-in lithium battery and no external
power supply needed;
l USB1.1 interface. Provide DLL and demonstration software to
facilitate development;
l Support USB charging and also the charging indicator, the low
battery indicator
CHARACTERISTICS
l Absolute Maximum Rating
| ITEM | SYMBOL | VALUE | UNIT |
| Charging Voltage | VCC | 6 | V |
| Operating Temp. | TOPR | -10~+70 | ℃ |
| Storage Temp. | TSTR | -20~+85 | ℃ |
l Electrical Specification
| ITEM | SYMBOL | MIN | TYP | MAX | UNIT |
| Charging Voltage | VCC | 4.2 | 5 | 5.5 | V |
| Charging Current | IBAT | | 500 | | mA |
| Standby Current | ISTBY | | 14 | 20 | mA |
| Continuous RF Current | IRF | | 100 | 200 | mA |
| Frequency | FREQ | 902 | | 928 | MHz |
| Effective Distance* | DIS | 0 | 70 | 100 | mm |
| Size | L×W×H | | 110 × 50 × 5.8 | | mm |
